| RSP 02 58 Profibus DP |
| multi-turn encoder |
 |
 |
|
|
|
|
|
| operating voltage |
10...30 VDC |
| resolution |
25 Bit |
| steps/turns |
8192 |
| turn |
4096 |
| code |
binary |
| interface |
Profibus DP |
| current consumption |
Max. 100 mA (w/o load) |
| speed |
|
| protection type |
IP 65 |
| highlights |
on-board diagnosis system,
rotational speed output |
|
|
|
|
|
| |
| RSH 75 P Profibus DP |
| multi-turn encoder |
|
 |
|
|
|
|
|
| operating voltage |
10...30 VDC |
| resolution |
25 Bit |
| steps/turns |
8.192 |
| turn |
4.096 |
| code |
binary |
| interface |
Profibus DP |
| current consumption |
max. 100 mA (w/o load) |
| speed |
|
| protection type |
Max. IP 54 |
| highlights |
on-board diagnosis system,
rotational speed output |
|
|
|
|
|
| |
| RSF 58 P Profibus DP |
| single/multi-turn encoder |
|
|
|
|
|
|
|
| operating voltage |
10...30 VDC |
| resolution |
10 up to 29 Bit |
| steps/turns |
1.024 or 8.192 |
| turn |
1 or 65.536 |
| code |
binary |
| interface |
Profibus DP |
| current consumption |
Max. 100 mA (w/o load) |
| speed |
|
| protection type |
IP 65 |
| highlights |
on-board diagnosis system,
rotational speed output |
|
|
|
|
|
| |
| RSF 59 P Profibus DP |
| single/multi-turn encoder |
|
|
|
|
|
|
|
| operating voltage |
10...30 VDC |
| resolution |
18 or 31 Bit |
| steps/turns |
262.144 |
| turn |
1 or 8.192 |
| code |
binary |
| interface |
Profibus DP |
| current consumption |
Max. 120 mA (w/o load) |
| speed |
|
| protection type |
IP 65 |
| highlights |
on-board diagnosis system,
rotational speed output |
|
|
|
|
|
| |
| RSHF 75 P Profibus DP |
| single/multi-turn encoder |
|
|
|
|
|
|
|
| operating voltage |
10...30 VDC |
| resolution |
10 up to 29 Bit |
| steps/turns |
1.024 or 8.192 |
| turn |
1 or 65.536 |
| code |
binary |
| interface |
Profibus DP |
| current consumption |
Max. 100 mA (w/o load) |
| speed |
|
| protection type |
Max. IP 54 |
| highlights |
on-board diagnosis system,
rotational speed output |
|
|
|
|
|
| |
| RSF 58 C CAN-Bus |
| single/multi-turn encoder |
|
|
|
|
|
|
|
| operating voltage |
10...30 VDC |
| resolution |
10 up to 29 Bit |
| steps/turns |
1.024 or 8192 |
| turn |
1 or 65.536 |
| code |
binary |
| interface |
CAN-Bus |
| current consumption |
Max. 100 mA (w/o load) |
| speed |
|
| protection type |
IP 65 |
| highlights |
on-board diagnosis system |
|
|
|
|
|
| |
| RSF 59 C CAN Bus |
| single/multi-turn encoder |
|
|
|
|
|
|
|
| operating voltage |
10...30 VDC |
| resolution |
18 or 31 Bit |
| steps/turns |
262.144 |
| turn |
1 or 8.192 |
| code |
binary |
| interface |
CAN-Bus |
| current consumption |
Max. 120 mA (w/o load) |
| speed |
|
| protection type |
IP 65 |
| highlights |
on-board diagnosis system |
|
|
|
|
|
| |
| RSHF 75 C CAN Bus |
| single/multi-turn encoder |
|
|
|
|
|
|
|
| operating voltage |
10...30 VDC |
| resolution |
10 up to 29 Bit |
| steps/turns |
1.024 or 8.192 |
| turn |
1 or 65.536 |
| code |
binary |
| interface |
CAN-Bus |
| current consumption |
Max. 100 mA (w/o load) |
| speed |
|
| protection type |
Max. IP 54 |
| highlights |
on-board diagnosis system |
|
|
|
|
|
| |
| RSF 58 Co CANopen |
| single/multi-turn encoder |
|
|
|
|
|
|
|
| operating voltage |
10...30 VDC |
| resolution |
10 up to 29 Bit |
| steps/turns |
1.024 or 8.192 |
| turn |
1 or 65.536 |
| code |
binary |
| interface |
CANopen |
| current consumption |
Max. 100 mA (w/o load) |
| speed |
|
| protection type |
IP 65 |
| highlights |
on-board diagnosis system |
|
|
|
|
|
| |
| RSF 59 Co CANopen |
| single/multi-turn encoder |
|
|
|
|
|
|
|
| operating voltage |
10...30 VDC |
| resolution |
18 or 31 Bit |
| steps/turns |
262.144 |
| turn |
1 or 8.192 |
| code |
binary |
| interface |
CANopen |
| current consumption |
Max. 120 mA (w/o load) |
| speed |
|
| protection type |
IP 65 |
| highlights |
on-board diagnosis system |
|
|
|
|
|
| |
| RSHF 75 Co CANopen |
| single/multi-turn encoder |
|
|
|
|
|
|
|
| operating voltage |
10...30 VDC |
| resolution |
10 up to 29 Bit |
| steps/turns |
1.024 up to 8.192 |
| turn |
1 or 65.536 |
| code |
binary |
| interface |
CANopen |
| current consumption |
Max. 100 mA (w/o load) |
| speed |
|
| protection type |
Max. IP 54 |
| highlights |
on-board diagnosis system |
|
|
|
|
|
| |
| RSF 58 D DeviceNET |
| single/multi-turn encoder |
|
|
|
|
|
|
|
| operating voltage |
10...30 VDC |
| resolution |
10 up to 29 Bit |
| steps/turns |
1.024 or 8.192 |
| turn |
1 or 65.536 |
| code |
binary |
| interface |
DeviceNet |
| current consumption |
Max. 100 mA (w/o load) |
| speed |
|
| protection type |
IP 65 |
| highlights |
on-board diagnosis system |
|
|
|
|
|
| |
| RSF 59 D DeviceNET |
| single/multi-turn encoder |
|
|
|
|
|
|
|
| operating voltage |
10...30 VDC |
| resolution |
18 or 31 Bit |
| steps/turns |
262.144 |
| turn |
1 or 8.192 |
| code |
binary |
| interface |
DeviceNet |
| current consumption |
Max. 120 mA (w/o load) |
| speed |
|
| protection type |
IP 65 |
| highlights |
on-board diagnosis system |
|
|
|
|
|
| |
| RSHF 75 D DeviceNET |
| single/multi-turn encoder |
|
|
|
|
|
|
|
| operating voltage |
10...30 VDC |
| resolution |
10 up to 29 Bit |
| steps/turns |
1.024 or 8.192 |
| turn |
1 or 65.536 |
| code |
binary |
| interface |
DeviceNet |
| current consumption |
Max. 100 mA (w/o load) |
| speed |
|
| protection type |
IP 54 |
| highlights |
on-board diagnosis system |
|
|
|
|
|
| |
| RSI 58 Interbus S |
| multi-turn encoder |
|
 |
|
|
|
|
|
| operating voltage |
10...30 VDC |
| resolution |
25 Bit |
| steps/turns |
8.192 |
| turn |
4.096 |
| code |
binary |
| interface |
Interbus S |
| current consumption |
Max. 60 mA (w/o load) |
| speed |
|
| protection type |
IP 65 |
| highlights |
parametrizable |
|
|
